TI德州儀器全差分放大器
發布時間：2021-10-29 17:11:22 瀏覽：964
全差分放大器是一種多功能工具，能夠替代balun(或一起使用)，提供多種多樣優勢。與以往的單端輸出放大器相比較，電路設計師在應用全差分放大器實現的全差分信號處理頻譜分析儀時，能夠提高電路對外界噪聲的抗擾性，因此使動態范圍增長，降低偶爾諧波。
TI德州儀器行業內領先的全差分放大器失真率低，可驅動精密和高速模數轉換器(ADC)。除此之外，它們特別適合驅動精密和高速數模轉換器(DAC)的輸出。TI德州儀器的FDA支持單端到差分和差分到單端的基本功能。
深圳市立維創展科技有限公司，專注于TI 德州老品牌可推出的新品，并備有備品系列儲備，可當天上線。
詳情了解TI德州儀器請點擊：/brand/57.html
或聯系我們的銷售工程師： 0755-83050846 QQ ： 3312069749
Part number | Number of channels
(#) | Total supply voltage
(Min)
(+5V=5, +/-5V=10) | Total supply voltage
(Max)
(+5V=5, +/-5V=10) | BW @ Acl
(MHz) | Acl, min spec gain
(V/V) | Slew rate
(Typ)
(V/us) | Vn at flatband
(Typ)
(nV/rtHz) | Iq per channel
(Typ)
(mA) | Vos (offset voltage @ 25 C)
(Max)
(mV) | Operating temperature range
(C) | Output current
(Typ)
(mA) |
THS4567 | 1 | 3.3 | 6 | 70 | 10 | 500 | 4.2 | 2 | 10 | -40 to 125 | 20 |
THP210 | 1 | 3 | 36 | 7 | 1 | 15 | 3.7 | 0.95 | 0.04 | -40 to 125 | 31 |
OPA1637 | 1 | 3 | 36 | --- | --- | 15 | --- | 0.95 | 0.2 | -40 to 125 | 31 |
OPA862 | 1 | 3 | 12.6 | 44 | 2 | 140 | 2.3 | 3.1 | 0.325 | -40 to 125 | 60 |
THS4561 | 1 | 2.85 | 12.6 | 60 | 1 | 230 | 4 | 0.78 | 0.25 | -40 to 125 | 27 |
LMH5401-SP | 1 | 3.15 | 5.25 | 4100 | 5 | 17500 | 1.25 | 60 | 5 | -55 to 125,
25 to 25 | 50 |
THS4552 | 2 | 2.7 | 5.4 | 150 | 1 | 220 | 3.3 | 1.37 | 0.265 | -40 to 125 | 65 |
THS4551 | 1 | 2.7 | 5.4 | 150 | 1 | 220 | 3.3 | 1.35 | 0.175 | -40 to 125 | 45 |
THS4541-Q1 | 1 | 2.7 | 5.4 | 620 | 1 | 1500 | 2.2 | 10.1 | 0.45 | -40 to 125 | 100 |
LMH5401 | 1 | 3.15 | 5.25 | 6200 | 2 | 17500 | 1.25 | 55 | 5 | -40 to 85 | 50 |
LMH3401 | 1 | 3.15 | 5 | 7000 | 6.3 | 18000 | 1.4 | 55 | 3.2 | -40 to 85 | 50 |
THS4541 | 1 | 2.7 | 5.4 | 620 | 1 | 1500 | 2.2 | 10.1 | 0.45 | -40 to 125 | 100 |
THS4520-DIE | 1 | 3 | 5.25 | 620 | 1 | 570 | 2 | 14.2 | 2.5 | 25 to 25 | 105 |
THS4500-EP | 1 | 4.5 | 15 | 370 | 1 | 2800 | 7 | 23 | 7 | -55 to 125 | 120 |
THS4532 | 2 | 2.5 | 5.5 | 36 | 1 | 220 | 10 | 0.25 | 0.4 | -40 to 125 | 26 |
THS4531A | 1 | 2.5 | 5.5 | 36 | 1 | 220 | 10 | 0.25 | 0.4 | -40 to 125 | 26 |
THS4524-EP | 4 | 2.5 | 5.5 | 145 | 1 | 490 | 4.6 | 1 | 8 | -55 to 125 | 55 |
THS4531 | 1 | 2.5 | 5.5 | 36 | 1 | 220 | 10 | 0.25 | 1 | -40 to 125 | 26 |
LMH6551Q-Q1 | 1 | 3 | 11 | 370 | 1 | 2400 | 6 | 12.5 | 5 | -40 to 125 | 65 |
THS4521-HT | 1 | 2.5 | 3.6 | 104 | 1 | 377.5 | 4.6 | 1.1 | 5 | -55 to 175,
-55 to 210 | 35 |
LMP8350 | 1 | 5 | 12 | 118 | 1 | 507 | 4.6 | 18 | 4 | -40 to 85 | 36 |
THS770006 | 1 | 4.75 | 5.25 | 2400 | 2 | 3200 | 1.7 | 100 | 5 | -40 to 85 | 80 |
LMH6554 | 1 | 4.7 | 5.25 | 2800 | 1 | 6200 | 0.9 | 52 | 3 | -40 to 125 | 150 |
THS4524 | 4 | 2.5 | 5.5 | 145 | 1 | 490 | 4.6 | 1.14 | 2 | -40 to 85 | 55 |
THS4521 | 1 | 2.5 | 5.5 | 145 | 1 | 490 | 4.6 | 1.14 | 2 | -40 to 85 | 55 |
THS4522 | 2 | 2.5 | 5.5 | 145 | 1 | 490 | 4.6 | 1.14 | 2 | -40 to 85 | 55 |
THS4509-Q1 | 1 | 3 | 5.25 | 2000 | 2 | 6600 | 1.9 | 37.7 | 4 | -40 to 125 | 96 |
LMH6553 | 1 | 4.5 | 12 | 900 | 1 | 2300 | 1.2 | 29 | --- | -40 to 125 | 120 |
THS4511-SP | 1 | 3.75 | 5.25 | 1100 | 1 | 5100 | 2 | 39.2 | 4 | -55 to 125,
25 to 25 | 96 |
THS4513-SP | 1 | 3 | 5.5 | 1100 | 1 | 5100 | 2.2 | 37.7 | 4 | -55 to 125,
25 to 25 | 96 |
THS4520 | 1 | 3 | 5.25 | 620 | 1 | 570 | 2 | 14.2 | 2.5 | -40 to 85 | 105 |
LMH6552 | 1 | 4.5 | 12 | 1500 | 1 | 3800 | 1.1 | 19 | 16.5 | -40 to 85 | 80 |
LMH6555 | 1 | 3 | 3.6 | 1200 | 4.8 | 3000 | 3.9 | 120 | 50 | -40 to 85 | --- |
THS4511 | 1 | 3.75 | 5.25 | 1600 | 1 | 4900 | 2 | 39.2 | 4 | -40 to 85 | 96 |
THS4508 | 1 | 3.75 | 5.25 | 2000 | 2 | 6400 | 2.3 | 39.2 | 4 | -40 to 85 | 96 |
THS4513 | 1 | 3 | 5.5 | 1600 | 1 | 5100 | 2.2 | 37.7 | 4 | -40 to 85 | 96 |
THS4503-EP | 1 | 4.5 | 15 | 370 | 1 | 2800 | 6.8 | 23 | 6 | -55 to 125,
-55 to 60 | 120 |
LMH6551 | 1 | 3 | 12 | 370 | 1 | 2400 | 6 | 12.5 | 5 | -40 to 85 | 65 |
THS4509 | 1 | 3 | 5.25 | 2000 | 2 | 6600 | 1.9 | 37.7 | 4 | -40 to 85 | 96 |
LMH6550 | 1 | 4.5 | 12 | 400 | 1 | 3000 | 6 | 20 | 5 | -40 to 85 | 75 |
THS4504 | 1 | 4.5 | 15 | 260 | 1 | 1800 | 8 | 16 | 7 | -40 to 85 | 130 |
THS4505 | 1 | 4.5 | 15 | 260 | 1 | 1800 | 8 | 16 | 7 | -40 to 85 | 130 |
THS4503 | 1 | 4.5 | 15 | 370 | 1 | 2800 | 6.8 | 23 | 4 | 0 to 70,
-40 to 85 | 120 |
THS4501 | 1 | 4.5 | 15 | 370 | 1 | 2800 | 7 | 23 | 7 | -40 to 85,
0 to 70 | 120 |
THS4500 | 1 | 4.5 | 15 | 370 | 1 | 2800 | 7 | 23 | 7 | -40 to 85,
0 to 70 | 120 |
THS4120 | 1 | 3 | 3.5 | 100 | 1 | 55 | 5.4 | 11 | 8 | -40 to 85,
0 to 70 | 25 |
THS4121 | 1 | 3 | 3.5 | 100 | 1 | 55 | 5.4 | 11 | 8 | -40 to 85,
0 to 70 | 25 |
THS4150 | 1 | 4 | 33 | 150 | 1 | 650 | 7.6 | 17.5 | 7 | -40 to 85,
0 to 70 | 85 |
THS4151 | 1 | 4 | 33 | 150 | 1 | 650 | 7.6 | 17.5 | 7 | 0 to 70,
-40 to 85 | 85 |
THS4130 | 1 | 4 | 33 | 150 | 1 | 52 | 1.3 | 12.3 | 2 | -40 to 85,
0 to 70 | 85 |
THS4131 | 1 | 4 | 33 | 150 | 1 | 52 | 1.3 | 12.3 | 2 | -40 to 85,
0 to 70 | 85 |
THS4140 | 1 | 4 | 33 | 160 | 1 | 450 | 6.5 | 13.2 | 7 | -40 to 85,
0 to 70 | 85 |
THS4141 | 1 | 4 | 33 | 160 | 1 | 450 | 6.5 | 13.2 | 7 | 0 to 70,
-40 to 85 | 85 |
